6000W Sine Wave Inverter

6000W Sine Wave Inverter
Product Code : SDH-6000W
Brand Name : SANDI
Product Description

Pure sine wave inverter is universally one of the major and advanced conversion of DC to AC, which has premium quality of sine wave AC output, have computers with central processor control, generally solid, less noise operation and pollution free. It is also applicable in the areas without any electricity, vehicles, ships, wind turbine, solar energy and so on. The inverter is also specialist in supplying AC voltage to every type of tool even air conditioners, televisions, refrigerator, fluorescent lights, electric fans electric motors, etc. Sine  wave is the output waveform. These kind of AC power are majorly applicable for the commercial use as well as for home appliances, this stem of power suppl is much more efficient than other upgraded sine wave and square wave.

Features:

  • It has a completely excellent PWM control know-how and electromagnetic compatibility plan
  • It has an intellectual design
  • It also has a broad DC input voltage series
  • Unadulterated sine wave output with high effectiveness and steadiness
  • It has an outstanding EMC design
  • Low output harmonic deformation THD 3%
  • It provides LED signals for usual output & breakdown and collapse state
  • In case of Short circuit, overload, over voltage and over temperature safe guard; and low battery voltage alarm and defense
  • It is utilized and fitted for a variety of AC loads purposes such as household machines, electric gadgets, industrial appliances and electronic video and audio.
  • It has an extensive working temperature series (industrial level)

Technical details:

Model

SDH-6000-121

SDH-6000-241

SDH-6000-481

SDH-6000-122

SDH-6000-242

SDH-6000-482

Rated Power

6000W

6000W

6000W

6000W

6000W

6000W

Max. Continuous Power

12000W

12000W

12000W

12000W

12000W

12000W

DC input voltage

12V

24V

48V

12V

24V

48V

AC output voltage

110VAC

220VAC

No-load current

2A

1A

0.5A

2A

1A

0.5A

AC output frequency

50Hz/60HZ

AC output waveform

Pure Sine Wave

Waveform distortion

THD<2%(Linear load)

Efficiency

>85%

>88%

>90%

>85%

>88%

>90%

DC input voltage range

10.5-15V

21-30V

42-60V

10.5-15V

21-30V

42-60V

Low Voltage Alarm

10.5+/-0.3V

21+/-0.3V

42+/-0.3V

10.5+/-0.3V

21+/-0.3V

42+/-0.3V

Low Voltage Shutdown

10+/-0.3V

20+/-0.3V

40+/-0.3V

10+/-0.3V

20+/-0.3V

40+/-0.3V

Over Voltage Protection

15.5+/-0.5V

31+/-1V

62+/-2V

15.5+/-0.5V

31+/-1V

62+/-2V

Low Voltage Recovery

12+/-0.5V

24+/-1V

48+/-2V

12+/-0.5V

24+/-1V

48+/-2V

Over Voltage Recovery

14.8V

29.5V

59V

14.8V

29.5V

59V


Protective Function

Low/Over voltage: LED Red light, automatic recovery

Over load: LED Red light, automatic recovery

Over temperature : LED Red light, automatic recovery

Short circuit: LED Red light, automatic recovery

Input reverse connection: Fuse burn-out

Working Temp.

0ƒ-40ƒ

Storage Temp. Humidity

-30ƒ-70ƒ

Dimension

540 x 240 x 220mm

Weight

16.5kg
