Inverter Built in Solar Charge Controller

Inverter Built in Solar Charge Controller
Inverter Built in Solar Charge Controller
Product Code : SDP-30KW
Brand Name : SANDI
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Specifications
  • Current
  • 45.45 Ampere (amp)
  • Frequency
  • 50/60 Hertz (HZ)
  • Output
  • single/ split/ 3 phase
  • Measuring Range
  • 240-600VDC Celsius (oC)
  • Sensor Type
  • current/voltage sensors
  • Display
  • LCD
  • Product Type
  • DC to AC inverter
  • Operating Temperature
  • -25~+55 Celsius (oC)
  • Working Temperature
  • -30~+55 Celsius (oC)
  • Input
  • 240Vdc or 360Vdc
  • Pressure Type
  • DC to AC
  • Diameter
  • 600 Millimeter (mm)
  • Application
  • solar system
  • Supply Voltage
  • single/ split/3 phase Volt/Ohm (v/ohm)
  • Accuracy
  • 1 %
  • Dimension(L*W*H)
  • 600*700*1150 Millimeter (mm)
  • Weight
  • 270 Kilograms (kg)
  • Warranty
  • 2 years
Product Description

Introduction

Over-voltage may lead to the degradation of battery performance. Keeping this in view, we offer Built in Controller for the Solar Charge Inverter that helps in the prevention of overcharging complete discharging of a battery. With the help of our offered Charge Controller help in limiting the rate that uses electric current to be either added to electric batteries or drawn from it. It can be used as stand alone device or can also be used while integrating it with a pack of battery.

Usage

It is highly demanded to be used in the following systems:

  • Solar power system

  • Wind power system

  • Wind-Solar hybrid system

  • And other renewable energy systems

Apart from being used in the aforementioned systems. It is also used to output a high quality and AC voltage with pure sine wave to various power supplies that has AC load.

Benefits of using the Inverter Built In Solar Charge Controller

  • The mentioned controller has been built using Japanese Mitsubishi IPM intelligent module.

  • Designed with modular approach, its simple structure makes helps in the easy maintenance.

  • It renders powerful protection against short circuit, extreme temperature and over loading to have safer and reliable systems with fault rate less than one percent.

  • Integrated with isolated transformer that has low frequency, maximum power output and can work all day long by ensuring that bus bar of AC and DC are completely isolated.

  • With little interference and harmonics, the controller offers constant voltage and frequency along with efficiency above ninety two percent.

  • Its excellent performance and convenient wiring helps in maintaining its service life up to fifteen years.

  • By setting the range of input voltage, output voltage and frequency ranging from 50 to 60 Hz can also be set with an accuracy less than 1 percent.

  • Besides, power priority for battery can also be set by setting up input for AC bypass.

  • Moreover, voltage range for DC input can also be set that renders convenience of adding extra solar panel in the future, if needed.

  • Depending upon the requirement, it can also be availed with built-in AC to DC battery charger or solar charge controller.

  • Includes three step charging technology such as high efficiency of charging, quick charging and equalize or float charging.

  • Works in two modes- Step down voltage start or variable frequency start. Its motor speed helps in driving motor with inductive load.

  • It also includes a bigger LCD display for displaying output frequency, output power, temperature, DC input voltage, fault code, AC bypass input voltage, phase current and voltage, etc.

  • Certified with CSA22.2, CE(EMC&LVD) and UL1741 certificates

Packaging and Services

  • The packaging is done in honeycomb carton of standard export that includes a wooden box or pallet

  • Controller can also be customized as per customers' requirement

  • Estimated delivery may take three to seven days

  • OEM and MOQ (single piece is available)

Trade Information
  • FOB Port
  • Ningbo/Shanghai
  • Payment Terms
  • Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal
  • Supply Ability
  • 6000pcs Per Month
  • Delivery Time
  • 7 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Packing of Inverter built in solar charge controller is standard export honeycomb cartoon with pallet or wooden box or OEM
  • Certifications
  • CE(EMC&LVD), SAA(AS4777&AS3100), G83, G59, VDE ARN 4105, UL1741, CSA22.2, ISO9001
