15000 Watt Power Pure Sine Wave Single

Model

SDP-15KW

Isolation mode

Low Frequency Transformer

DC Input

Rated voltage (Vdc)

96V

192V

240V

Rated current

156.25A

78A

62.5A

AC Output

Rated output power

15KW

Output waveform

Pure Sine Wave

Rated Voltage

220V 3%

110/220V 3%

380VAC3%

Phases

Single phase

Split phase 3 wires  ground

3 phase 4 wire

Rated current (A)

68A

68A

23A (phase current)

Frequency

50Hz or 60Hz

Rated output voltage range (V)

110/120/220/230/240/380/400/415/440VAC optional

Phases

Single / Two/ Three phase optional

Power Factor (PF)

>0.95

Overload Ability

150%, 5 seconds

Efficiency

>94%

Waveform distortion rate (THD)

<3 Linear load)

Dynamic Response
(0 to 100% load)

5 50ms

Display

LCD

Running mode

Working continuously

Electrical insulation properties

2000Vac, 1 Minute

AC Bypass Function

Optional

Solar Charge Controller built in

Optional

AC to DC battery Charger built in

Optional

RS485 remote monitoring

Optional

Wide voltage input 100-850VDC(optional)

Off grid inverter can work without battery

Protection Function

Protection

Input reverse polarity, under voltage, overvoltage, output over-current,

short circuit, overheating etc.

Cooling method

Fan-cooled

Short-circuit protection

No automatic recovery, need to restart the machine

Working environment

Noise ( 1 meter)

50db

Degree of protection

IP20(indoor)

Working Altitude (m)

2000

Working temperature

-25 55

relative humidity

0 90 non-condensing

Mechanical dimension

Depth x Width x Height

500x600x800mm

Weight (Kg)

140Kg

Certification

European CE(EMC & LVD), SAA
