Emergency Power Supply System

Emergency Power Supply System
Product Code : SDP-40KW
Brand Name : SANDI
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Price Range
  • 9000 - 11000 USD ($)
Product Specifications
  • Output
  • single / split/ three phase
  • Display
  • LCD
  • Frequency
  • 50 or 60 Hertz (HZ)
  • Sensor Type
  • Voltage/current sensors
  • Product Type
  • DC to AC inverter
  • Operating Temperature
  • -25~+60 Celsius (oC)
  • Pressure Type
  • DC to AC
  • Supply Voltage
  • 380/400/415/440/480Vac optional Volt/Ohm (v/ohm)
  • Warranty
  • 2 years
Product Description

Since establishment, we have been playing a lead role in manufacturing and exporting Emergency Power Supply System. We manufacture this equipment under the strict inspection of expert supervisors using best quality materials and components. It is used to supply AC voltage to all kinds of power tools, air conditioners, electric motors, refrigerators, fluorescent lights, televisions and electric fans. The equipment is provided with powerful data display and fault instruction function. We make available this Emergency Power Supply System for clients in different specifications as per their requirements. Also, we offer this equipment at reasonable prices.

The Power Supply is a device made for supplying electric power to an electrical load after converting the current into correct and needed load for keeping all kinds of power tools smoothly run even when the voltage is fluctuating. Exceptionally used for household and small work places, our product owns a simple yet technologically advanced design to convey excellent features for its long service life. Our on-time delivery of this Power Supply is admired by the valuable patrons’ spanning all across the world.

Features Solar Power Supply System:

  • Short circuit protection

  • Pure sine wave

  • Longer working life

Specifications:

Technical Data

Model

SDP-40KW

Isolation mode

Low Frequency Transformer

DC Input

Rated voltage (Vdc)

360V

Rated current

111A

AC Output

Rated output power

40KW

Output waveform

Pure Sine Wave

Rated Voltage

220V±3%

380VAC±3%

Phases

Single phase

3 phase 4 wire

Rated current

182A

61A (phase current)

Frequency

50Hz or 60Hz

Rated output voltage range (V)

220/230/240/380/400/415VAC optional

Power Factor

0.9

Overload Ability

150%, 5 seconds

Efficiency

>93%

Waveform distortion rate (THD)

<3% Linear load

Dynamic Response (0 to 100% load)

5% 50ms

Display

LCD

Running mode

Working continuously

Electrical insulation properties

2000Vac, 1 Minute

Protection Function

Protection

Input reverse polarity, under voltage, overvoltage, output over-current, short circuit, overheating etc.

Cooling method

Fan-cooled

Short-circuit protection

No automatic recovery, need to restart the machine

Working environment

Noise ( 1 meter)

50dB

Degree of protection

IP20 indoor

Working Altitude

2000

Working temperature

-25~+55℃

relative humidity

0~90% non-condensing

Mechanical dimension

Depth* Width * Height

650x750x1100mm

Weight Kg

350Kg

Trade Information
  • FOB Port
  • Ningbo/Shanghai
  • Payment Terms
  • Others, Paypal, Western Union, Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C)
  • Supply Ability
  • 1000 Per Month
  • Delivery Time
  • 10-12 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Packing of Emergency Power Supply System is strong honeycomb carton with pallet or wooden box
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • CE(EMC&LVD), SAA(AS4777&AS3100), G83, G59, VDE ARN 4105, UL1741, CSA22.2, ISO9001
