6 Input Pv Solar Array Combiner Boxes

6  Input Pv Solar Array Combiner Boxes
6 Input Pv Solar Array Combiner Boxes
Send Inquiry
Product Code : PVB-6/1
Brand Name : SANDI
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Specifications
  • Output
  • 1000VDC
  • Current
  • 60-90 Ampere (amp)
  • Product Type
  • solar dc combiner box
  • Operating Temperature
  • -25~+60 Celsius (oC)
  • Working Temperature
  • -25~+60 Celsius (oC)
  • Input
  • solar panel
  • Pressure Type
  • 1000VDC
  • Diameter
  • 400 Millimeter (mm)
  • Application
  • solar system
  • Supply Voltage
  • 1000 Volt/Ohm (v/ohm)
  • Dimension(L*W*H)
  • 27*40*10 Millimeter (mm)
  • Weight
  • 3.5 Kilograms (kg)
  • Warranty
  • 2 years
Product Description

6 ways in pv array combiner box/ solar junction box for solar power system

PV Combiner Box

In the solar photovoltaic system, solar photovoltaic arrays to reduce the connection between the inverter, according to the characteristics of PV systems, our company developed independently the PV combiner box, with the PV inverter products company to match the composition of the complete PV system solutions, which greatly simplify the wiring process, while inverter can operate under protection.

Combiner box for the collection of solar photovoltaic array outputs the DC current, the user can connect a number, the same specifications of PV panels in series to form a photovoltaic array, and then a number of PV arrays connected in parallel to the PVB series combiner box, after then, the output comes through the DC circuit breaker, and photovoltaic inverter, so as to constitute a complete photovoltaic power generation system, realization and power the grid.

 Features:

  • With reliable, lighting and surge protection, solar photovoltaic DC high voltage lighting protection device, all with positive doubt negative lightning protection function.
  • Wide range DC voltage input; DC high voltage circuit breaker with professional pressure range of 200~900Vdc, safe and reliable.
  • muti groups can simultaneously access PV array.
  • The port has a water resistant.
  • Wall structure with outdoor rain shell protection grade to IP65, to meet the application requirements for outdoor installation.
  • nstallation and maintenance simple, convenient, long service life.


Trade Information
  • FOB Port
  • Ningbo/Shanghai
  • Payment Terms
  • Paypal, Western Union, Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C)
  • Supply Ability
  • 1000 Per Day
  • Delivery Time
  • 1-2 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Packing of 6 Input Pv Solar Array Combiner Boxes is strong honeycomb carton
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • CE(EMC&LVD), SAA(AS4777&AS3100), G83, G59, VDE ARN 4105, UL1741, CSA22.2, ISO9001
