80 kW Solar Inverter with 3 Phase

Model

SDP-80KW

Isolation mode

Low Frequency Transformer

DC Input

Rated voltage (Vdc)

480V

Rated current（A）

167A

AC Output

Rated output power

80KW

Output waveform

Pure Sine Wave

Rated Voltage

380VAC ± 3%

Phases

3 phase 4 wire

Rated current（A）

121A (phase current)

Frequency

50Hz or 60Hz

Rated output voltage range (V)

380/400/415/440VAC optional

Power Factor（PF）

0.9

Overload Ability

150%, 5 seconds

Efficiency

>93%

Waveform distortion rate (THD)

<3%（Linear load）

Dynamic Response (0 to 100% load)

5%，≤50ms

Display

LCD

Running mode

Working continuously

Electrical insulation properties

2000Vac, 1 Minute

Protection Function

Protection

Input reverse polarity, under voltage, overvoltage, output over-current, short circuit, overheating etc.

Cooling method

Fan-cooled

Short-circuit protection

No automatic recovery, need to restart the machine

Working environment

Noise ( 1 meter)

≤50dB

Degree of protection

IP20（indoor）

Working Altitude（m）

≤2000

Working temperature

-25~+55℃

relative humidity

0~90%，non-condensing

Mechanical dimension

Depth* Width * Height

750x750x1480mm

Weight （Kg）

520Kg
