AC Three Phase Power Supply

AC Three Phase Power Supply
AC Three Phase Power Supply
Send Inquiry
Product Code : SDT-15KW
Brand Name : SANDI
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Price Range
  • 2800 - 3200 USD ($)
Product Specifications
  • Current
  • 22.7 Ampere (amp)
  • Display
  • LCD
  • Output Voltage
  • 220/230/240/380/400/415/440/480Vac optional Volt (V)
  • Waveform Distortion
  • Pure sine wave, THD <3%(Linear load)
  • Output
  • 3 phase 380-440Vac
  • Voltage Protection
  • Input under voltage, over voltage, output over-current, short circuit, overheating etc.
  • Sensor Type
  • current/voltage sensors
  • Ambient Temperature
  • -25~+55 Celsius (oC)
  • Frequency
  • 50/60 Hertz (HZ)
  • Rated Power
  • 15KW
  • Current Type
  • AC
  • Product Type
  • AC-DC-AC converter/ voltage converter/ phase converter/ frequency converter
  • Control System
  • SVPWM
  • Operating Temperature
  • -25~+55 Celsius (oC)
  • Efficiency
  • >94%
  • Frequency (MHz)
  • 50 or 60 Hertz (HZ)
  • Working Temperature
  • -30~+55 Celsius (oC)
  • Input Voltage
  • 110/120/220/230/240Vac optional Volt (V)
  • Input
  • single or split phase voltage
  • Pressure Type
  • AC-DC-AC inverter
  • Diameter
  • 550 Millimeter (mm)
  • Usage
  • Other
  • Phase
  • Three Phase
  • Application
  • power phase converter
  • Supply Voltage
  • 3 phase 380-440Vac Volt/Ohm (v/ohm)
  • Accuracy
  • 1 %
  • Dimension(L*W*H)
  • 550*550*860 Millimeter (mm)
  • Weight
  • 140 Kilograms (kg)
  • Warranty
  • 2 years
Product Description

Technical Specifications:

Model

SDT-15KW

Isolation

Low Frequency Transformer

AC Input

Input rated voltageï¼Ë†VACï¼â€°

Single phase 220V

Input rated currentï¼Ë†Aï¼â€°

68.2A

Input voltage range

110/120/220/230/240Vac optional

AC Output

Rated AC output power

15KW

AC output waveform

Pure sine wave

Phases

Three phase, 4 wires

Output rated voltage

380VAC Ã‚±3%

Output rated currentï¼Ë†Aï¼â€°

22.76A (per phase)

Output voltage range

220/240/380/400/415/440/480Vac optional

Output Frequency

50Hz/60Hz±0.05Hz

Power Factorï¼Ë†PFï¼â€°

0.95

Overload Ability

150%, 10s

Efficiency

>93%

Waveform distortion rate (THD)

<3%ï¼Ë†Linear loadï¼â€°

Crest Factor (CF)

3:1

Display

LCD

Electrical insulation properties

2500Vac, 1 Minute

Ambient temperature

-15~+55℃

Using environment humidity

0~90%ï¼Å’No condensation

Protection

Input under voltage, overvoltage, output over-current, short circuit, overheating etc.

Structure

Cooling method

Fan-cooled

Noise

<40dB

Degree of protection

IP20ï¼Ë†indoorï¼â€°

Using altitudeï¼Ë†mï¼â€°

≤3000

Dimensions (mm)

600x700x1200mm

Weight (Kg)

162Kg

CE Standard

EN60950-1:2006+A11:2009, EN61000-6-4:2007+A1:2001, EN61000-6-2:2005, EN61000-3-12:2005, EN61000-3-11:2000

Trade Information
  • FOB Port
  • Ningbo/Shanghai
  • Payment Terms
  • Others, Paypal, Western Union, Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C)
  • Supply Ability
  • 6000pcs Per Month
  • Delivery Time
  • 7 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Packing of AC Three Phase Power Supply is standard export honeycomb cartoon with pallet or wooden box or OEM
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • CE(EMC&LVD), SAA(AS4777&AS3100), G83, G59, VDE ARN 4105, UL1741, CSA22.2, ISO9001
