Grid Tie Inverter
PV/Wind grid-connected power system includes PV modules/wind turbine, grid-connected inverter, meter and power switch board. The PV modules/wind turbine convert the solar energy/wind energy to the DC power, then the grid-connected inverter the DC power to the sine wave AC power which has the same frequency and phase with the grid voltage. The AC power feed in the grid partly and the other powers supply the local loads.
Feature:
Specification:
Model | SDS- 5000W | |||
Isolation type | Transformerless | |||
DC Input | MPPT Voltage Range | DC100-500V |
| |
Max. DC Voltage | 500VDC |
| ||
Start Voltage | 180V |
| ||
Recommend PV Array Open Circuit Voltage | 200~400V |
| ||
Control System | MPPT |
| ||
AC Output | Rated Output Power | 5000W |
| |
Max. AC Output Current | 22.7A |
| ||
Grid Rate voltage | AC230V | AC380V |
| |
Grid Voltage range | AC 185264V | AC 342 418 V |
| |
Normal Grid Frequency | 50/60HzGrid frequency |
| ||
Phases | 1 phase 2 wire | 3 phase 4 wire |
| |
Power Factor | 0.95 |
| ||
Current THD | At rated power and in the sine wave <3% |
| ||
Control System | PWM |
| ||
Anti-islanding | 0.5 sec |
| ||
Output Overload | 100% |
| ||
Max. Efficiency | 98% |
| ||
Euro Efficiency | 97% |
| ||
Structure | Protection Class | IP20 |
| |
Cooling system | Natural cooling |
| ||
Power Consumption at Night | 0W |
| ||
Noise | 50dB |
| ||
Data Interfaces | External RS232C/RS485 |
| ||
Display | LCD |
| ||
Dimensions(WxHxD) | 640x375x285mm |
| ||
Weight | 28kgs |
| ||
Protection | Inverter | Input over voltage, output short circuit, overheat, output DC component. |
| |
Grid | Anti-islanding, over/under voltage of grid, over/under frequency of grid. |
| ||
Environment | Environment | No corrosion gas, flammable gas, oil mist, dust etc. |
| |
Operation temperature | -10,40,55 |
| ||
Stored temperature | -20,65 |
| ||
Relative humidity | 0-100% (Do not wet with dew) |
| ||
Warranty | 3-years quality warranty |
| ||
CE-Standards Complied | CE-Standards Complied: EN61000-6-2, EN61000-6-4(EMC), EN61558-1, EN61558-2-17, EN50178, EN61000-1, |
| ||
Certifications | CE, VDE0126-1, AS4777, AS3100, G83/1, G59. ISO9001:2000 |
|
