Lithium/LiFePo4 battery off grid inverter

Lithium/LiFePo4 battery off grid inverter
Lithium/LiFePo4 battery off grid inverter
Send Inquiry
Product Code : SDP-10KW
Brand Name : SANDI
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Price Range
  • 1700.00 - 2000.00 USD ($)
Product Specifications
  • Product Type
  • DC to AC inverter
  • Standard
  • CE
  • Rated Voltage
  • single phase or split phase or 3 phase Volt (V)
  • Frequency (MHz)
  • 50 or 60 Hertz (HZ)
  • Protection
  • IP20 or IP45
  • Usage
  • DC to AC off grid inverter
  • Size
  • 550*550*860mm
  • Color
  • white and green
  • Weight
  • 120 Kilograms (kg)
  • Dimension(L*W*H)
  • 550*550*860 Millimeter (mm)
Product Description
Lithium/LiFePo4 battery off grid inverter

Introduction:

SANDI SDP series low frequency off grid inverter suitable for Lithium/LiFePo4 battery, it has high conversion efficiency, high instantaneous power and low loss, output pure sine wave suitable for capacitive, inductive and nonlinear mixed-load, full power output with stronger capacity to drive load, perfect protection function against over load, short circuit, over temperation, under/over voltage, improper operation etc, which won't cause inverter failure. Suitable for all kind of AC load, widely used in solar system, wind system, solar-wind hybrid system.

Features:

 Easy to repair

Adopted Japanese Mitsubishi IPM intelligent module, modular and simple structure design, very easy and convenient for maintenance, any fault only need use send you parts for replacement, maintenance is low-skill work.

Little fault rate

It with powerful protection for short circuit, over load and over temperature which is more safe and reliable. Fault rate < 2%.

100% full power stable output

Inside with full power low frequency isolated transformer, 100% full power output, can work 24h*7, which ensure the AC busbar and DC busbar are completely isolated, the harmonic and interference is very little, constant voltage and constant frequency stable output.

High efficiency

Efficiency > 94%

AC bypass input(optional)

AC power priority or battery power priority can be set

Setting flexible

The DC input voltage range(under voltage point, under voltage recovery point, over voltage point, over voltage recovery point, under voltage recovery time) all can be set, convenient for adding or reducing the quantity of solar panel or battery in the future. The output voltage and output frequency can be set too.

Two kinds of start mode

Variable frequency start and Step down voltage start. With stronger capacity to drive inductive load.

Big LCD display

Parameters:

  • Model: SDP- 3KW ~ 50KW
  • AC output power: 3KW ~ 50KW
  • DC Input: 48V/96V/120V/192V/240V/360V/480V/750V (Optional )
  • AC Output: 120V/220V/380V/415V/440V/480VAC  (Optional)
  • Phase: Single phase or Split phase or Three Phase
  • Frequency: 50Hz or 60Hz
  • Power Factor: 0.99
  • Overload: 150% for 30 seconds
  • Efficiency: >93%
  • Waveform Distortion: <3%
  • Isolation Mode: Low Frequency Transformer
  • Insulation Properties: 2000 vac, 1 minute
Trade Information
  • FOB Port
  • Ningbo/Shanghai
  • Payment Terms
  • Paypal, Western Union, Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C)
  • Supply Ability
  • 1000pcs Per Month
  • Delivery Time
  • Delivery time of Lithium/LiFePo4 battery off grid inverter is 6-7 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Packing of Lithium/LiFePo4 battery off grid inverter is standard export honeycomb cartoon or wooden box, accept OEM
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • CE, SAA, UL, CSA
