Pv Dc Combiner Box 2 In 1 Out For Solar Panel

Pv Dc Combiner Box 2 In 1 Out For Solar Panel
Pv Dc Combiner Box 2 In 1 Out For Solar Panel
Send Inquiry
Product Code : PVB-2/1
Brand Name : SANDI
Price And Quantity
  • Minimum Order Quantity
  • 1 Unit
  • Price Range
  • 4900.00 - 5500.00 USD ($)
Product Specifications
  • Current
  • 20-30 Ampere (amp)
  • Output
  • 1000VDC
  • Product Type
  • solar dc combiner box
  • Operating Temperature
  • -25~+60 Celsius (oC)
  • Working Temperature
  • -25~+60 Celsius (oC)
  • Input
  • solar panel
  • Pressure Type
  • 1000VDC
  • Diameter
  • 190 Millimeter (mm)
  • Application
  • solar system
  • Supply Voltage
  • 1000 Volt (v)
  • Dimension(L*W*H)
  • 350*190*110 Millimeter (mm)
  • Weight
  • 1.64 Kilograms (kg)
  • Warranty
  • 2 years
Product Description

PV DC Combiner Box 2 in 1 out for solar panel

PV combiner box is used to bring together the output DC current of the PV array
It will combine the same solar panels which in series to form a PV array, supporting the use of photovoltaic grid connected inverter, so as to constitute a complete photovoltaic system, with the city electric grid.
Our PVB PV array combiner box series is specially-designed for meeting the need of high performance and high reliability of PV systems
In combining with our solar access inverters, Sandi PVB provides a turnkey solution for PV power plant systems. By using PV array combiner box, according to the input voltage of the inverter, Clients can connect a fixed number of similar PV modules to form a PV array. Then different strings of PV array can be converged into the PV array string box.
After that, together with lightning arresters and circuit breakers, it is  connecting to the inverter to reduce the system installation time and increase the system safety.


  • Applicable for outdoor PV systems
  • Each PV array attached to DC fuse protection and anti-reverse protection optional
  • Wide DC voltage input range with maximum open-circuit voltage up to 1000V
  • High voltage lightning protection (SPD) special for PV
  • PV MC4 connector input, convenient and safe system wiring
  • PV special high voltage circuit breaker control output
  • Protection class IP65 for outdoor use
  • Monitoring feature optional for each string of PV array
  • Output waterproof terminals

Technical Data

Type Designation PVB-2/1
DC Input
DC input strings 2 strings
Max. allowable input voltage 1000V
 Each string rated input current 10A
Each string input Max current 10A fuse
DC Output
DC output strings 1 string
DC rated output current 20A
Output DC Circuit Breaker 25A
Other parameters
Lighting and surge protection Yes
Input fuse protection Yes
Reverse Polarity protection Yes
Protection Class IP65
Output Terminal Type PG21 Cable Glands
Box material IP65 ABS plastic box
Environment Temperature -25~+60℃
Environment Humidity <90% No condensation
Installation:indoors/outdoors outdoor


Trade Information
  • FOB Port
  • Ningbo/Shanghai
  • Payment Terms
  • Paypal, Western Union, Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C)
  • Supply Ability
  • 6000 Unit Per Month
  • Delivery Time
  • 7 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Packing of Pv Dc Combiner Box 2 In 1 Out For Solar Panel is strong honeycomb carton
  • Main Domestic Market
  • All India
  • Certifications
  • CE(EMC&LVD), SAA(AS4777&AS3100), G83, G59, VDE ARN 4105, UL1741, CSA22.2, ISO9001
