6kw Ac-Ac 1ph 230v To 3ph 400v Converter
Product Code : SDT-6KW
Brand Name : Sandi
- Rated Power
- Waveform Distortion
- Pure sine wave, THD <3%（Linear load）
- Ambient Temperature
- -25~+55 Celsius (oC)
- Voltage Protection
- Input under voltage, over voltage, output over-current, short circuit, overheating etc.
- Current Type
- Output Voltage
- 220/230/240/380/400/415/440/480Vac optional Volt (V)
- Product Type
- AC-DC-AC converter/ voltage converter/ phase converter/ frequency converter
- Control System
- Frequency (MHz)
- 50 or 60 Hertz (HZ)
- Input Voltage
- 110/120/220/230/240Vac optional Volt (V)
- Three Phase
- 95 Kilograms (kg)
- 450*550*760 Millimeter (mm)
- 2 years
Single Phase to 3 Phase Converter
Our SDT series Power Phase converter is one of the most advanced AC to AC conversion products in the world which can convert ordinary single-phase power to industrial three-phase power. The converter can supply AC power to all kinds of electric equipment, electric motors, pump, compressor, and other industrial power supply. Applicable to all types of load.
- The input voltage, output voltage, frequency and phase can be custom made.
- Two kinds of start mode: Step Down Voltage Start and Variable Frequency Start. VFD is especially used for taking 3 phase inductive load more easily. This function is very convenient for users and also reduce frequency converters usage, which reduced the cost of equipment investment, easy to connect wires and control.
- Output AC Power is suitable for all types of home appliances,electric tools, electric motors etc.
- Using the fifth generation efficient IPM intelligent module from Japanese Mitsubishi, high efficiency and stable performance. It with powerful protection function for short circuit, over load, over temperature. Service life can reach 15-20 years.
- Pure sine wave output. with good transient response, little harmonic distortion, higher conversion efficiency and stable output voltage features.
- Adopted low frequency isolated transformer, safe and reliable, single phase input power is completely isolated from three phase output power, high conversion efficiency, high instantaneous power, stable performance and low load loss.
- Adopts new magnetism material, largely reduce machine consumption, making efficiency maximum up to 98%.
- Adopts America DSP chip, safe and reliable.
- Adopts black pure aluminum radiator, which confirms the best radiating performance
- Converter has the function of filtering the grid disturbance and interference at the same time, which is a good performance of stabilized voltage and frequency power, to provide a more stable and pure power supply environment for the back end devices
- Intelligent fan speed control system, low no-load loss
- LCD display, high efficiency, easy installation
- The output frequency 50Hz/60Hz can be set
Low Frequency Transformer
Input rated voltage VAC
Single phase 220V
Input voltage range
Input rated current A
Rated AC output power
AC output waveform
Pure sine wave
Three phase, 4 wires
Output rated voltage
Output voltage range
Output rated current
9.1A (per phase)
Waveform distortion rate (THD)
<3% Linear load
Crest Factor (CF)
Electrical insulation properties
2500Vac, 1 Minute
Using environment humidity
0~90% No condensation
Input under voltage, overvoltage, output over-current, short circuit, overheating etc.
Degree of protection
Using altitude m
EN60950-1:2006+A11:2009, EN61000-6-4:2007+A1:2001, EN61000-6-2:2005, EN61000-3-12:2005, EN61000-3-11:2000
- FOB Port
- Payment Terms
- Others, Paypal, Western Union, Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C)
- Supply Ability
- 1000 Per Month
- Delivery Time
- 4-5 Days
- Sample Available
- Sample Policy
- Contact us for information regarding our sample policy
- Packaging Details
- Packing of 6kw Ac-Ac 1ph 230v To 3ph 400v Converter is standard export honeycomb carton with pallet or wooden box
- Main Export Market(s)
- Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
- Main Domestic Market
- All India
- CE(EMC&LVD), SAA(AS4777&AS3100), VDE ARN 4105, UL1741&CSA22.2, G83, G59, ISO9001
